| Item | Unit | α-S100iB | α-S130iB | |||||||||
| Tonnage | kN | 1000 | 1300 | |||||||||
| Maximum and minimum die height | mm | Double platen 450 – 150 Single platen 520 – 220 |
Single platen 570 – 200 | |||||||||
| Clamping stroke | mm | 350 | 400 | |||||||||
| Platen size (HxV) | mm | 660 x 610 | 730 x 730 | |||||||||
| Screw diameter | mm | 22 | 26 | 28 | 32 | 36 | 40 | 26 | 28 | 31 | 36 | 40 |
| Maximum injection volume | cm3 | 29 | 50 | 58 | 103 | 147 | 181 | 50 | 58 | 103 | 147 | 181 |
| Maximum Injection speed | mm/s | 200/350/550/650/750 | 200/350/550 | |||||||||
